SSR 4A/32VDC/CTRL3-10VDC

SSR 4A/32VDC/CTRL3-10VDC

Kogege tõhusat alalisvoolu juhtimist meie MOSFET alalisvoolu väljundmooduliga. Sellel on tugev türistori reiting 4A ja maksimaalne lülitusvool 4A, muutes selle ideaalseks mitmesugustes rakendustes, alates hõõglampide ja LED-ide juhtimisest kuni kontaktorite ja PLC sisendite/väljunditeni. Kavandatud hõlpsaks paigaldamiseks trükkplaatidele, see töötab lülituspingega 0-32VDC ja juhtimispingega 3-10VDC. Vastavuses CE, EAC, UKCA ja UL standarditega, tagab see teie elektrivajadustele parima kvaliteedi ja ohutuse.
Specifications:
Product: MOSFET DC Output Module
Thyristor Rating: 4A
Max. Switching Current (A): 4A
Type of Mounting: PCB
Number of Poles: 1 - Single phase
Function: DC on/off
Switching Voltage Rate: 0-32VDC
Control Voltage Rate: 3-10VDC

Standards:
CE
EAC
UKCA
UL (cURus)

Features:
Product Code: SSR 4A/0-32VDC/CTRL 3-10VDC
Type of Relay: DC
Series: SP-ST-SL
Heatsink Included: No
DC Technology: MOSFET
Terminals (Power): “PCB” pins
Housing Type: Interface relays

Application:
(AC-5a / LC D) Incandescent light bulbs and infrared lamps
(AC-5b/DC-6) LEDs
(AC-14/AC-15/DC-13/DC-14) Contactors
PLC Inputs/Outputs
30.42 € 30.42 € (Tax excluded)

  • Min thyristor rating per phase (A)
  • Relay application
  • Relay control voltage nominal
  • Relay enclosure
  • Relay function
  • Relay heatsink
  • Relay max switching current per phase 40c a
  • Relay number of poles
  • Relay output protection type
  • Relay standards
  • Relay switching voltage
  • Relay terminals
  • Relay type AC DC
  • Relay type of mounting
  • Weight
Add to cart
Add to wishlist
Terms and Conditions
Prices exclude VAT.
Documents
CC_DC.pdf FT_SLD0 5.pdf

Manufacturer Part Number: SLD01205
Internal Reference: EE-100-188-145

Specifications

Relay application Ac 14 ac 15 dc 13 cc 14 contactors, Ac 5a lc d incandescent light bulbs and infrared lamps, Ac 5b dc 6 leds, Plc inputs outputs
Relay standards CE, EAC, UKCA, UL cURus
Min thyristor rating per phase (A) 4
Relay control voltage nominal 5/12/24 VDC
Relay enclosure Interface relays
Relay function Dc on off
Relay heatsink No (Relay heatsink)
Relay max switching current per phase 40c a 4
Relay number of poles Single phase
Relay output protection type TVS
Relay switching voltage 0–110 VDC
Relay terminals Pcb pins
Relay type AC DC DC
Relay type of mounting Pcb (Relay type of mounting)
Weight 0.0035 kg
