SSR 25A/400VAC/CTRL 4-14V/450A²S

SSR 25A/400VAC/CTRL 4-14V/450A²S

Kogege täpset ja usaldusväärset juhtimist meie AC null-ristumise väljundmooduliga. Sellel on 22A türistori hinnang ja maksimaalne lülitusvool 22A, mis tagab tõhusa jõudluse laias valikus rakendustes. Ideaalne kütteelementide, mootorite, lampide, LED-ide, transformaatorite ja kondensaatorite juhtimiseks. See töötab sujuvalt lülituspingega vahemikus 24-600VAC ja juhtpingega vahemikus 4-14VDC. Vastavuses CE, EAC, UKCA ja UL standarditega, see moodul tagab tipptasemel kvaliteedi ja ohutuse kõigile teie elektrivajadustele.
Specifications
Output Type: AC Zero Cross
Thyristor Rating: 22A
Max. Switching Current (A): 22A
Type of Mounting: PCB
Number of Poles: 1 - Single Phase
Function: AC on/off Zero-Cross
Switching Voltage Rate: 24-600VAC
Control Voltage Rate: 4-14VDC

Standards
CE
EAC
UKCA
UL (cURus)

Features
Relay Type: AC
Series: SK
Heatsink Included: NO
Terminals (Power): “PCB” pins
Housing Type: PCB relay

Applications:
(AC-1 / LC A) Heating elements
(AC-3 / LC B) Motors
(AC-5a / LC C) Discharge lamps
(AC-5a / LC D) Incandescent light bulbs and infrared lamps
(AC-5b/DC-6) LEDs
(AC-6a / LC E) Transformers
(AC-6b / LC F) Capacitors
(AC-14/AC-15/DC-13) Electrovalves and electromagnets
(AC-14/AC-15/DC-13/DC-14) Contactors
71.37 € 71.37 € (Tax excluded)

  • Min thyristor rating per phase (A)
  • Relay application
  • Relay control voltage nominal
  • Relay enclosure
  • Relay function
  • Relay heatsink
  • Relay max switching current per phase 40c a
  • Relay number of poles
  • Relay standards
  • Relay switching voltage
  • Relay terminals
  • Relay type AC DC
  • Relay type of mounting
  • Weight
Add to cart
Add to wishlist
Terms and Conditions
Prices exclude VAT.
Documents
CC_Mono TOR.pdf FT_SKL10240.pdf

Manufacturer Part Number: SKL10240
Internal Reference: EE-100-188-114

Specifications

Relay application Ac 14 ac 15 dc 13 cc 14 contactors, Ac 14 ac 15 dc 13 electrovalves and electromagnets, Ac 3 lc b motors, Ac 5a lc c discharge lamps, Ac 5a lc d incandescent light bulbs and infrared lamps, Ac 5b dc 6 leds, Ac 6a lc e transformers, Ac 6b lc f capacitors, Ac1 lca heating elements
Relay standards CE, EAC, UKCA, UL cURus
Relay switching voltage 110/120 VAC, 230 VAC, 400 VAC, 480 VAC, 600 VAC
Min thyristor rating per phase (A) 20 29 (Min thyristor rating per phase (A))
Relay control voltage nominal 5/12/24 VDC
Relay enclosure Pcb relay
Relay function Ac on off zero crossing
Relay heatsink No (Relay heatsink)
Relay max switching current per phase 40c a 20 29 (Relay max switching current per phase 40c a)
Relay number of poles Single phase
Relay terminals Pcb pins
Relay type AC DC AC
Relay type of mounting Pcb (Relay type of mounting)
Weight 0.0126 kg
