SSR 25A/400VAC/CTRL 5-30VDC

SSR 25A/400VAC/CTRL 5-30VDC

SC862110 väiksema vooluga ühefaasiline vahelduvvoolu väljundmoodul nullpunktilülitimise ja väljundkaitsega (25A) pakub kompaktset ja kulutõhusat lahendust erinevateks väiksema vooluga vahelduvvoolu lülitamise vajadusteks. See 25A moodul on varustatud integreeritud ülepingekaitsega ja toetab laia valikut vahelduvvoolu koormusi. Ideaalne tööstusautomatiseerimiseks, hoonete automatiseerimiseks, turvasüsteemideks ja muuks. (Jahutusradiaator vajalik, müüakse eraldi)
Specifications:
Thyristor Rating: Equivalent to 25A (SSR Technology)
Max. Switching Current (A): 25A (de-rating required for continuous operation)
Type of Mounting: Screw mount
Number of Poles: 1 (Single phase)
Function: AC On/Off (Zero-Cross)
Switching Voltage Rate: 24-520VAC (Wide AC Range)
Control Voltage Rate: 5-30VDC (Standard Control Voltage Range)
Standards: CE, EAC, UKCA, UL (cULus), VDE

Features:
Lower Current AC Output: 25A / 24-520VAC (SSR Technology) - Ideal for lower power applications
Wide Switching Voltage Range
Standard Control Voltage Range: 5-30VDC
Screw Terminals for Secure Connections
Zero-Cross Switching - Reduces Electrical Noise and Transients
Integrated RC Snubber Circuit - Provides Output Surge Protection
Suitable for Various AC Loads (de-rating may apply):
Heating Elements (AC-1 / LC A)
Discharge Lamps (AC-5a / LC C)
Incandescent Bulbs and Infrared Lamps (AC-5a / LC D)
LEDs (AC-5b/DC-6)
Capacitors (AC-6b / LC F) Use with Caution and Consult a Qualified Engineer
Electrovalves and Solenoids (AC-14/AC-15/DC-13)
Contactors (AC-14/AC-15/DC-13/DC-14)
Series: SC8
Heatsink: Required (Sold Separately) - A properly sized heatsink is crucial for safe operation, especially at higher loads or ambient temperatures.
Housing Type: Hockey Puck

Applications:
Industrial Automation Systems (Lower Power AC Loads)
Building Automation Systems (Lighting Control, HVAC Systems - Lower Power)
Machine Control (AC Solenoid Activation)
Security Systems (Powering Sensors or Devices)
DIY and Hobbyist Projects (Lower Current AC Control)
118.61 € 118.61 € (Tax excluded)

  • Min thyristor rating per phase (A)
  • Relay application
  • Relay control voltage nominal
  • Relay enclosure
  • Relay function
  • Relay heatsink
  • Relay max switching current per phase 40c a
  • Relay number of poles
  • Relay output protection type
  • Relay standards
  • Relay switching voltage
  • Relay terminals
  • Relay type AC DC
  • Relay type of mounting
  • Weight
Add to cart
Add to wishlist
Terms and Conditions
Prices exclude VAT.
Documents
CC_Mono TOR.pdf FT_SC862110.pdf IS_SC.pdf

Manufacturer Part Number: SC862110
Internal Reference: EE-100-187-888

Specifications

Relay application Ac 14 ac 15 dc 13 cc 14 contactors, Ac 14 ac 15 dc 13 electrovalves and electromagnets, Ac 5a lc c discharge lamps, Ac 5a lc d incandescent light bulbs and infrared lamps, Ac 5b dc 6 leds, Ac 6b lc f capacitors, Ac1 lca heating elements
Relay control voltage nominal 24 VDC, 5/12/24 VDC
Relay standards CE, EAC, UKCA, UL cURus, VDE
Relay switching voltage 110/120 VAC, 230 VAC, 400 VAC, 480 VAC
Min thyristor rating per phase (A) 20 29 (Min thyristor rating per phase (A))
Relay enclosure Hockey puck
Relay function Ac on off zero crossing
Relay heatsink No (Relay heatsink)
Relay max switching current per phase 40c a 20 29 (Relay max switching current per phase 40c a)
Relay number of poles Single phase
Relay output protection type Rc
Relay terminals Screws
Relay type AC DC AC
Relay type of mounting Screw (Relay type of mounting)
Weight 0.0951 kg
