SENSOR 1NO + LOOP (4PINS)

SENSOR 1NO + LOOP (4PINS)

PWA11500 on mitmekülgne lähedus- ja olemasoluandur, mis on mõeldud objektide tuvastamiseks erinevates rakendustes, eriti aga neis, kus on vajalik täiendav ohutuselement. Tänu ühele normaalselt avatud (1NO) kontaktile koos 4-punktilise ohutusringiga ja kinnitamisklambriga pakub see sensor lihtsat paigaldamist ja täiustatud ohutusfunktsioone. Anduri ühendamiseks kasutatakse kaablit.
Technical Specifications:
Max Switching Power: 10VA/W

Standards: CE, UKCA

Features:
1 Normally Open (1NO) Contact with Safety Loop (4-points)
Clip-on Mounting
Material: Plastic
Connection Type: Cable (length not included - see accessories)
Max Switching Voltage: 100VDC
Max Switching Current: 0.40A
Sensor Series: PW

Application: Clearance, Presence (Safety Focus)
21.26 € 21.26 € (Tax excluded)

  • Sensor application
  • Sensor contact type
  • Sensor material
  • Sensor max switching current
  • Sensor max switching power
  • Sensor max switching voltage
  • Sensor mounting
  • Sensor standards
  • Weight
Add to cart
Add to wishlist
Terms and Conditions
Prices exclude VAT.
Documents
FT_PW__1LM00100_2YB40080.pdf

Manufacturer Part Number: PWA11500
Internal Reference: EE-100-187-184

Specifications

Sensor application Distance, Presence
Sensor max switching voltage 100 VDC, 48 VAC
Sensor standards CE, Ukca (Sensor standards)
Sensor contact type 1no safety loop
Sensor material Plastic (Sensor material)
Sensor max switching current 0 4
Sensor max switching power 10va (Sensor max switching power)
Sensor mounting Clip
Weight 0.004 kg
