DIN rail power supply 24W 24V 1A

Technical data		Information
Brand	Mean Well	Commodity	8504409090
Item number	MDR-20-24	Warranty pack	36 Months Bring-In
Series	MDR-20	RoHS	Compliant
Description	AC-DC Industrial DIN rail power supply; Output 24Vdc at 1A; plastic case	Packing quantity	72
Application	Installation UL 508 ITE EN/UL/IEC 60950	Net weight (gram)	181.666666666667
Technology	AC/DC
Power Format	DIN rail
Output Power (W)	20
Output Voltage (V)	24
Output Current (A)	1
Input Voltage (V)	90 - 264 Universal Input 110/230V
IP Rating	No IP assigned
Width (mm)	22.5
Height (mm)	90
Depth (mm)	100
Control Signals	DC OK
Dimming Technology	No Dimming

11.90 € (Tax excluded)

Terms and Conditions
Prices exclude VAT.

Documents

MDR-20-spec.pdf

Manufacturer Part Number: MDR-20-24
Internal Reference: EE-100-184-897

Weight

0.19 kg
