LED driver 40W 12V 3.34A

Technical data		Information
Brand	Mean Well	Commodity	8504409090
Item number	LPF-40-12	Warranty pack	60 Months Bring-In
Series	LPF-40	RoHS	Compliant
Description	AC-DC Single output LED driver Mix mode (CV+CC); Output 12Vdc at 3.34A; cable output	Packing quantity	32
Application	LED EN 61347	Net weight (gram)	420
Technology	AC/DC Constant Current C.C. Constant Voltage C.V.
Power Format	Box Type - Enclosed
Output Power (W)	40
Output Voltage (V)	12
Output Current (A)	3.34
Input Voltage (V)	90 - 305 Universal Input 110/230V
IP Rating	IP20 IP21 IP30 IP40 IP42 IP50 IP64 IP65 IP66 IP67
Width (mm)	42.5
Height (mm)	32
Depth (mm)	162.5
Dimming Technology	No Dimming

21.50 € (Tax excluded)

Terms and Conditions
Prices exclude VAT.

Documents

LED_EN.pdf LPF-40-spec.pdf

Manufacturer Part Number: LPF-40-12
Internal Reference: EE-100-185-220

Weight

0.44 kg
