Certifications |
FCC, CE, UL 61010-1, UL 61010-2-201, ISA 12.12.01, Class 1 Div 2 |
|
Dimensions |
46 x 99 x 142 mm (W*D*H) |
|
EMI |
FCC Class A |
|
EMS |
EN61000-4-2,3,4,5,6,8, EN61000-6-2,4 |
|
Ethernet Port |
8*RJ45 Ports w/10/100Tx (PSE 30W/Port) |
|
Free fall / Shock / Vibration |
IEC60068-2-32; IEC60068-2-27; IEC60068-2-6 |
|
Gigabit Combo Port |
2*10/100/1000Tx RJ45 and 2*100/1000 SFP Slot For Fiber |
|
Green |
RoHS Compliant |
|
Housing / Mounting |
IP30 rated Metal Housing, DIN-Rail or Wall Mounting |
|
Humidity |
5 to 95%, (non-condensing) |
|
Humidity |
5 to 95%, (non-condensing) |
|
Operating Temperature |
STD: -10° to 75° C |
|
Overload Current Protection |
Present |
|
PoE Pin Out |
V+, V+, V-, V- for pins 1,2,3,6 Endspan, MDI Alternative A |
|
Power Consumption |
210W@48V; 250W@51-55V (Full Load w/ PoE) |
|
Power Input |
48~55VDC, Redundant Input |
|
Power Reverse Polarity Protection |
Yes |
|
Protection |
EFT: 2KV; ESD: 6KV |
|
Standards |
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3at |
|
Storage Temperature |
-40°C ~ 85°C |
|
Switching Architecture |
Non-Blocking Switching Fabric |
|
Warranty |
5 Years |
|
Weight |
Unit 1.5lbs.; Shipping Weight 2.0 lbs.
|
