Ambient Relative Humidity |
5% to 95% (non-condensing) |
|
Antenna |
Two External SMA Antennas: 3dBi for 2.4GHz, 5dBi for 5GHz (MIMO support, Dual 2Tx/2Rx) |
|
Certifications |
FCC, CE, NCC, RCM |
|
Dimensions |
46 x 162 x 110 mm (W x H x D) |
|
EMI |
FCC Part 15 Subpart B
CE EN 55032,
EN301489-1/-17
FCC Part 15 subpart B
CNS13438
AS/NZS CSIPR 32 |
|
EMS |
CE EN 55024
IEC61000-4-2 (ESD),
IEC61000-4-3 (RS),
IEC61000-4-4 (EFT),
IEC61000-4-5 (Surge),
IEC61000-4-6 (CS),
IEC61000-4-8 (Magnetic Field)
IEC61000-4-11 |
|
Ethernet Port |
WAN: 10/100/1000Mbps
LAN: 10/100/1000Mbps |
|
Green |
RoHS Compliant |
|
Housing |
Metal, IP30 protection |
|
IEEE 802.11 a/n/ac |
5.15G~5.25GHz, 5.725G~5.85GHz |
|
IEEE 802.11 b/g/n |
2.412G~2.462GHz |
|
Input Voltage |
9 to 24VDC |
|
Mounting |
DIN-Rail Mounting, Wall Mounting |
|
Operating Temperature |
-40°C to 70°C |
|
Power Connection |
2-pin terminal block |
|
Power Consumption |
18.9 Watts |
|
Protocols |
IP, TCP, UDP, ARP, BOOTP, ICMP, HTTP, HTTPS, DNS Proxy, NAPT, SNTP, RADIUS, Dynamic DNS, SMTP, SNMP |
|
Reverse Polarity Protection |
Present |
|
RF |
FCC Part 15 Subpart C/E
CE-RED
EN300328
EN301893
EN301489-1/-17
LP0002
AS/NZS 4268 |
|
RF Radiation Exposure |
EN62311
FCC Part 2.1091 |
|
Safety |
EN60950-1
CNS14336-1 |
|
Standards |
IEEE 802.11a/b/g/n/ac
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Fast Ethernet
IEEE 802.3ab 1000Base-T Gigabit Ethernet |
|
Storage Temperature |
-40°C to 80°C |
|
USB |
Configuration backup/restore, firmware update |
|
Warranty |
5 Years |
|
Weight |
Unit: 1.622 lbs.
Shipping: 2.336 lbs. |
|
WiFi Encryption |
WEP, WPA, WPA2, TKIP, AES Interface |
|
WLAN |
Dual Radio 2.4GHz/5GHz concurrent |
|
WLAN Operation Mode |
AP/Client/Bridge/Repeater |
