8 x Gigabit PoE+ porti
120W PoE võimsuse eelarve
16Gbps kommutatsioonivõimsus
IEEE 802.1p QoS ja DSCP läbipääsu tugi
Kompaktne ventilaatorita disain
Seinale paigaldatav metallist korpus
NDAA / TAA nõuetele vastav (ainult USA ja Kanada)
Standards
IEEE 802.3
IEEE 802.3u
IEEE 802.3ab
IEEE 802.3x
IEEE 802.3p
IEEE 802.3af
IEEE 802.3at
Device Interface
8 x Gigabit PoE+ ports
LED indicators
Data Transfer Rate
Ethernet: 10Mbps (half duplex), 20Mbps (full duplex)
Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex)
Gigabit Ethernet: 2000Mbps (full duplex)
Performance
Switch Fabric: 16Gbps
RAM Buffer: 192KB
MAC Address Table: 4K entries
Jumbo Frames: 9KB
Forwarding rate: 11.9Mpps (64-byte packet size)
Special Features
802.1p Class of Service (CoS)
Wall mountable
Power
Input: 100 – 240 V AC, 50/60Hz, 2.5A
Output: 55V DC, 2.55A external power adapter
Max. consumption: 126W
PoE
PoE budget: 120W
PoE Mode A: Pins 1,2 for power and pins 3,6 for power
Operating Temperature
0° – 40° C (32° – 104° F)
Operating Humidity
Max. 90% non-condensing
Dimensions
240 x 105 x 27mm (9.45 x 4.13 x 1.1 in.)
Weight
580g (20.45 oz.)
Certifications
CE
FCC
LVD
