Compact Industrial Gigabit Ethernet Media Converter, with 10/100/1000TX to SC Connector Single Fiber (WDM-A), Single-Mode 10km, TX1310nm - RX1550nm; EOT: -40° to 80°C

Ambient Relative Humidity 5% to 95%, (non-condensing)
Certifications FCC, CE
Dimensions 26 x 95 x 75 mm (W x H x D)
EMI FCC Part 15 Subpart B Class A, CE EN 55032 Class A, EN 61000-6-4 Class A
EMS CE EN 55024 Class A
EN 61000-6-2 Class A
IEC61000-4-2 (ESD)
IEC61000-4-3 (RS)
IEC61000-4-4 (EFT)
IEC61000-4-5 (Surge)
IEC61000-4-6 (CS)
IEC61000-4-8 (Magnetic Field)
Ethernet Port 1*RJ45 Port w/10/100/1000T(X), auto negotiation speed, Full/Half duplex mode, and auto MDI/MDI-X connection
Fiber Port 1*1000 SC/ST type connector
Multi-mode: 50/125um or 62.5/125um
Single-mode: 9/125um or 10/125um
Flow Control IEEE 802.3x back pressure flow control
Free Fall / Shock / Vibration IEC60068-2-32 / IEC60068-2-27 / IEC60068-2-6
Green RoHS Compliant
Housing Metal, IP30 protection
Input Voltage 12 to 48VDC, Redundant Input
Jumbo Frame 10K bytes
LED Indicators Power (PWR): On / Off
Fiber Port (GFX): Link / Act
Ethernet Port: Link / Act
MAC Table Size 8K
Memory Buffer 1Mbit
Mounting DIN-Rail, Wall Mounting (optional)
Operating Temperature -40°C to 80°C
Overload Current Protection Present
Power Connection 1 removable 4-contact terminal block
Power Consumption 2.2 Watts for system
Processing Type Store and Forward
Protocols CSMA/CD
Reverse Polarity Protection Present
Standards IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Fast Ethernet
IEEE 802.3ab 1000Base-T Gigabit Ethernet
IEEE 802.3z 1000Base-X Gigabit Fiber
Storage Temperature -40°C to 85°C
Warranty 5 Years
Wavelength Depends on fixed fiber modules
Weight Unit: 0.595 lb.
Shipping: 0.86 lb.
390.00 € 390.00 € (Tax excluded)

  • Weight
Add to cart
Add to wishlist
Terms and Conditions
Prices exclude VAT.
Documents
Antaira_IMC-C1000-XX series_Datasheet-v1.1.pdf

Manufacturer Part Number: IMC-C1000-WA-S1-T
Internal Reference: EE-100-169-796

Specifications

Weight 0.25 kg
